Kussmaul Status Center, Single Battery Display 091-189-12
The Kussmaul Status Center, Single Battery Display 091-189-12 is a universal indicator for vehicles with a single battery system.
The indicator reads battery voltage, and indicates the condition of the battery via LED's: High Voltage, Fully Charged, Charging and Low Voltage. The High Voltage and Low Voltage LED's blink to indicate that there may be a problem with the vehicles electrical system. In addition to the LED status indicators, a 3-digit indicator displays the battery voltage with an accuracy of 100 millivolts.
The unit is designed to be mounted on the outside of a vehicle to readily indicate the battery condition. The indicator fits Kussmaul standard indicator panel cut outs, and comes with a 3 year warranty.
Features:
- LED's indicate status of battery condition
- 3 digit display shows battery voltage
- LED flashes when low or high voltage is reached
- Weatherproof enclosure
- Available in 24V
- 3 year warranty
Specifications:
| Input | 12 Vdc From Battery |
| Warranty | 3 Years |
| Weight | .25 Lbs |
| LED Voltage Set Points | High Voltage - 14.82 Vdc And Above , Fully Charged - 13.08 Vdc To 14.82 Vdc , Charging - 12.84 Vdc To 13.08 Vdc , No LED's On - 12.30 Vdc To 12.84 Vdc , Low Voltage - 12.30 Vdc And Below |
| Digital Display | Yes |
| DC Volts | Yes |
