Kussmaul EJECT SPRING, AUTO EJECT WP 091-18-008
The Kussmaul EJECT SPRING, AUTO EJECT WP 091-18-008 is a coupling device wired between an Auto Eject and the vehicle, and serves to only connect the A.C. power after the plug has been inserted into the Auto Eject.
Upon vehicle startup, the Dynamic Disconnect opens the load circuit before ejecting the plug. By providing the time delays on both application, and removal of power, no arcing can occur at the connector. Note A.C.power must be present at the shoreline connector, in order to operate the Dynamic Disconnect.
Features:
- 30A contacts
- Totally eliminates connector arcing
- Disconnects load before Auto Eject is ejected
- Time delay connects load after Auto Eject is plugged in
- Works on both the WP and Super Auto Ejects
- 3 year warranty
Specifications:
| Input | 12 Vdc |
| Warranty | 3 Years |
| Weight | .25 Lbs |
| Relay Contacts | 30 Amps |
| Auto Eject | Yes |
